Creality CR Otter 3D Scanner

Creality CR-Scan Otter 3D Scanner

Unleashing Precision, Versatility, and Innovation for All Your Scanning Needs

The Creality CR-Scan Otter 3D Scanner is an advanced solution for capturing objects of any size with ultra-high precision and unmatched efficiency. Whether you're scanning intricate small objects or larger items, the CR-Scan Otter ensures a smooth and seamless scanning experience with its cutting-edge design and innovative features.

Key Features

Innovative Four-Lens Stereo Vision

The Otter is equipped with two sets of dual lenses to handle a wide range of scanning tasks:

• Long-Focal Dual Lenses: For capturing fine details in small objects.
• Short-Focal Dual Lenses: Designed for larger objects, offering comprehensive coverage.

Capture Objects Big and Small

The CR-Scan Otter excels in versatility, supporting a scanning range from 10x10x10mm to 2000x2000x2000mm, making it ideal for both tiny items like coins and massive structures like vehicles. Its working distance of 110mm to 1200mm ensures adaptability to various object sizes.

Ultra-High Precision and Detail-Rich Scans

With scanning precision up to 0.02mm, the Otter captures every detail with sharpness and accuracy, faithfully reproducing the texture and contours of the object.

Anti-Shake Technology for Smooth Scanning

With a scanning speed of up to 20 fps and One-Shot 3D Imaging Technology, the Otter maintains a stable and efficient scanning process, even for handheld use. Its robust backtracking system reduces tracking loss for uninterrupted operation.

Scan Black and Metal Objects Without Spraying

The Otter's advanced algorithms allow you to scan challenging surfaces, such as black and reflective materials, without the need for scanning spray, making it perfect for car parts, tires, and other industrial objects.

Full-Color Scanning for True-to-Life Reproduction

The 24-bit full-color RGB camera and exclusive color mapping algorithms ensure exceptional texture and colour accuracy. Built-in LED lights enable detailed scans even in low-light conditions.

Cross-Platform Compatibility and Wireless Scanning

The CR-Scan Otter works seamlessly across Windows and macOS platforms and is ready for future wireless scanning capabilities on iOS and Android with the upcoming accessories.

Enhanced User Experience

Real-time exposure adjustment, touch buttons, and audible feedback simplify the scanning process. The ring indicator lights provide immediate feedback on scanning status for a seamless experience.

Technical Specifications

• Accuracy: Up to 0.02mm
• 3D Resolution: 0.05–2mm
• Scanning Speed: Up to 20fps
• Minimum Scan Volume: 10x10x10mm
• Single Capture Range: Max 1350x840mm @ 1000mm
• Technology: Infrared structured light
• Working Distance: 110mm–1000mm
• Color Mapping: Yes
• Alignment Modes: Geometry, Marker, Texture
• Output Formats: OBJ, STL, PLY
• IMU: Yes
• Supplemental Lighting: 2 white LEDs
• Marker Recognition: Enhanced with 8 infrared LEDs
• Laser Safety: Class I (eye-safe)
• System Compatibility: Windows, macOS
• Wireless Scanning: Supported with accessory
• Operating Temperature: -10°C to 40°C
• Operating Humidity: 0–90% RH
• Input Power: 5V 3A
• Data Interface: USB Type-C (3.0/2.0)
• Dimensions: 165mm x 37mm x 59mm
• Weight: 390g

What’s in the Box?

• Creality CR-Scan Otter 3D Scanner
• Instruction Manual

Applications

• Industrial Design & Manufacturing: Reverse engineering, quality assurance.
• Art & Design: Digitising sculptures, creating digital art assets.
• Education & Research: Interactive teaching and 3D visualisation.
• 3D Printing: Creating precise models for prototyping and production.

The Creality CR-Scan Otter 3D Scanner redefines possibilities in 3D scanning. With its advanced technology, versatile features, and ultra-high precision, it’s the perfect tool for creators, engineers, and innovators looking to elevate their work to the next dimension.
